Introducing TKFAN’s high powerful DC brushless fan series, engineered for extreme thermal management, high-velocity forced-air cooling, and maximum volumetric airflow (CFM) output. Designed with heavy-duty motor stators and reinforced aerodynamic blades, these high-performance axial fans deliver deep cross-ventilation to quickly dissipate intense heat loads from concentrated electronic and industrial systems.
Voltage 12V
32000rpm/min
Max 38.5 cfm,1.6 kpa
Voltage 12V
21700rpm/min
Max 66.8 cfm,1.4 kpa
Voltage 48V
6000rpm/min
Max 378.6 cfm,0.51 kpa
Voltage 48V
5000rpm/min
Max 361.69 cfm,0.45 kpa
Voltage 24V
2500rpm/min
Max 742.8 cfm,0.19 kpa
Explore our comprehensive performance parameter matrix below to quickly identify the optimal high powerful DC fan for your high-density servers, telecommunication enclosures, industrial machinery, and high-impedance thermal layouts. Compare key specifications including frame dimensions, operational voltage, rotational speed (RPM), airflow output (CFM), and maximum static pressure capability (kPa).
| Model / Series | Size (mm) | Voltage (V) | Speed (RPM) | Airflow (CFM) | Max Pressure (kPa) |
|---|---|---|---|---|---|
| DA4028VH12X | 40*40*28 | 12V | 32,000 | 38.5 | 0.95 |
| DA6038VH12B-B | 60*60*38 | 12V | 21,700 | 66.8 | 0.65 |
| DA14038HV48X-D | 140*140*38 | 48V | 6,000 | 378.6 | 0.51 |
| DA17251HV48X | 172*150*51 | 48V | 5,000 | 361.69 | 0.45 |
| DA25489H24B | 254*89 | 24V | 2,500 | 742.8 | 0.19 |
Integrating a high powerful fan into high-density electronics or industrial hardware requires exact thermal matching. Under severe system backpressure, airflow drops significantly if static pressure ratings are insufficient. TKFAN high-power axial fans combine specialized blade aerodynamics with heavy-duty motor drives to maintain continuous, high-CFM airflow even through restricted air passages.
Engineered for extreme performance, capable of reaching speeds up to 32,000 RPM and delivering over 370+ CFM airflow for demanding enterprise equipment.
Built with UL94V-0 flame-retardant PBT housings, dual Japanese ball bearings, and dynamic balance tuning for continuous heavy-duty operation.
When heat sinks and circuit components are packed tightly, air resistance increases exponentially. TKFAN high powerful fans leverage optimized blade pitch angles and static vane designs to concentrate air momentum, ensuring laminar flow penetration directly through thermal hotspots.
Explore High Powerful Series →Review expert answers to common engineering questions regarding high-power DC fan selection, RPM tuning, thermal performance, and customization.
High powerful fans are specifically engineered with ultra-high rotational speeds (up to 32,000 RPM), high static pressure ratings, and reinforced motor structures. They deliver significantly higher airflow volume (CFM) to penetrate dense thermal barriers in servers, telecom cabinets, and power equipment where standard fans fail.
Key applications include 1U/2U rackmount servers, telecommunication base stations, EV charging stations, medical equipment, industrial automation, energy storage systems, and high-impedance thermal chassis.
Our high-power fans utilize dynamic balance calibration, dual precision ball bearing systems, and reinforced PBT frame structures with anti-vibration rubber dampers. This guarantees smooth operation and long-term mechanical reliability under continuous high-speed rotation.
Yes, we support 4-wire customization including PWM (Pulse Width Modulation) speed control, Speed Signal (FG) tachometer output, and RD alarm signals for real-time monitoring via host controllers or ECUs.
We offer standard 12V, 24V, and 48V DC options. Customized wide-voltage input ranges can also be tailored according to specific system power supply constraints.
Static pressure represents the fan's ability to push air through tight air channels, narrow heatsinks, and dense PCB layouts. High static pressure ensures air actually flows past hot components rather than stalling at the inlet due to backpressure.
All our high-power models feature imported Japanese dual ball bearings, offering an expected operating life of up to 50,000–70,000 hours at 40°C ambient temperatures.
Yes. We offer fully encapsulated motor vacuum potting technology, granting IP68 waterproof and dustproof protection for outdoor harsh environments, moisture, salt spray, and extreme dust.
Standard wiring, connector, or parameter adjustments can be prototyped within 48 hours. Fully bespoke structural or aerodynamic tuning samples are available within 1-2 weeks.
Yes, every custom delivery comes with factory inspection documentation, including AMCA 210 air performance curves, PQ charts, thermal imaging analysis, and acoustic spectrum reports.
TKFAN heavy-duty high powerful DC fans are widely utilized in enterprise server racks, industrial power inverters, commercial welding machinery, cryptocurrency mining rigs, telecommunication enclosures, and high-density electronic control cabinets.
