Voltage 24V
3700rpm/min
Max 148.4 cfm,0.35 kpa
Detailed mechanical dimensions drawing of the CA15035-A series centrifugal fan, highlighting mounting holes, casing outline, and outlet specifications for installation integration.
Performance P-Q (Airflow vs. Static Pressure) characteristic curve for the CA15035-A centrifugal fan, illustrating operating efficiency across various system backpressures.
Technical specification table to assist in selecting the optimal CA15035-A centrifugal fan model based on voltage, input power, speed, airflow, static pressure, and noise ratings.
| Model | P/N Code | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| VDC | VDC | Amp | Watt | R.P.M | M³/min | CFM | mmH2O | InH2O | dB-A | ||
| PART.NO. | AY | VDC | VDC | Amp | Watt | R.P.M | M³/min | CFM | mmH2O | InH2O | dB-A |
| CA15035HV24X | 24 | 18~26.5 | 0.77 | 18.48 | 3700 | 4.504 | 159.15 | 36.56 | 1.439 | 64.3 | |
| CA15035HV48X | 48 | 36~54 | 0.385 | 18.48 | 3700 | 4.504 | 159.15 | 36.56 | 1.439 | 64.3 | |
We can customize voltage (5V/12V), wire length, and connectors. Prototypes ready in 48 hours.
