Micro blower BA3004L05X-A
Voltage 5V
11000rpm/min
Max 0.73 cfm,0.09 kpa
Request a Sample
Technical Specifications
Micro blower BA3004-A Selection Guide
Compare voltage, dimensions, speed, airflow, and static pressure to select the perfect micro blower for your equipment design.
| Model | P/N Code | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| VDC | VDC | Amp | Watt | R.P.M | M³/min | CFM | mmH2O | InH2O | dB-A | ||
| BA3004L05X | AY | 5 | 1.9~6 | 0.07 | 0.35 | 11000 | 0.021 | 0.73 | 9.57 | 0.376 | 28.6 |
| BA3004L03X | 3 | 1.9~6 | 0.05 | 0.165 | 7000 | 0.011 | 0.39 | 3.05 | 0.120 | <18 | |
| BA3004L02X | 2 | 1.9~6 | 0.03 | 0.06 | 4300 | 0.007 | 0.26 | 1.16 | 0.046 | <18 | |
Need a Custom Modification?
We can customize voltage (5V/12V), wire length, and connectors. Prototypes ready in 48 hours.
Contact Our Engineers
