Micro blower BA1804L05B-A
Voltage 5V
13000rpm/min
Max 0.2 cfm,0.06 kpa
Request a Sample
Technical Specifications
Micro blower BA1804-A Selection Guide
Compare voltage, dimensions, speed, airflow, and static pressure to select the perfect micro blower for your equipment design.
| Model | P/N Code | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| M³/min | CFM | mmH2O | InH2O | ||||||||
| PART.NO. | VDC | VDC | Amp | Watt | R.P.M | M³/min | CFM | mmH2O | InH2O | dB-A | |
| BA1804L3.3X | AY | 3.3 | 2 ~ 6 | 0.03 | 0.1 | 10000 | 0.004 | 0.14 | 3 | 0.12 | 19 |
| BA1804L05X | 5 | 2 ~ 6 | 0.04 | 0.2 | 13000 | 0.006 | 0.2 | 6 | 0.24 | 21.7 | |
Micro Blower BA1804-A Performance Demonstration
Watch our Micro Blower BA1804-A series demonstrate exceptional airflow and static pressure performance in live testing.
Looking for different sizes or specifications?
Explore our full range of Micro blower, or choose from similar models below.
Micro blower
Need a Custom Modification?
We can customize voltage (5V/12V), wire length, and connectors. Prototypes ready in 48 hours.
Contact Our Engineers
