Low operating voltage Blower BA3510H05B-A
Low operating voltage Blower BA3510H05B-A
Voltage 5V
10000rpm/min
Max 2.2 cfm,0.1 kpa
Ultra-Compact Form Factor (35x35x10mm)
Designed specifically for micro-electronics and tight enclosures, this 35mm micro blower seamlessly fits into space-constrained devices without sacrificing thermal efficiency.
Low Operating Voltage & High Efficiency (5V DC)
Engineered with a 5V low operating voltage architecture, it is perfectly optimized for battery-powered, USB-interfaced, or portable smart hardware to maximize energy savings.
High-Precision Brushless DC Motor (BLDC)
Utilizing advanced brushless technology, the BA3510H05B delivers friction-free commutation, ensuring a remarkably stable airflow output and an extended operational lifespan.
Silent Cooling Operation (Low Noise)
Precision balancing and an aerodynamic blade design minimize acoustic vibration, providing quiet heat dissipation ideal for noise-sensitive smart home or wearable applications.
Technical Specifications
Low operating voltage Blower BA3510-A Selection Guide
Compare voltage, dimensions, speed, airflow, and static pressure to select the perfect micro blower for your equipment design.
| Model | P/N Code | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| M³/min | CFM | mmH2O | InH2O | ||||||||
| PART.NO. | VDC | VDC | Amp | Watt | R.P.M | M³/min | CFM | mmH2O | InH2O | dB-A | |
| BA3510LL05X | AY | 5 | 1.8~3.6~6.8 | 0.1 | 0.5 | 5500 | 0.035 | 1.25 | 2.67 | 0.105 | 25.4 |
| BA3510L05X | 5 | 1.8~3.6~6.8 | 0.12 | 0.6 | 6000 | 0.040 | 1.42 | 3.62 | 0.143 | 27.5 | |
| BA3510LV05X | 5 | 1.8~3.6~6.8 | 0.13 | 0.65 | 6500 | 0.041 | 1.45 | 4.25 | 0.167 | 29.6 | |
| BA3510M05X | 5 | 1.8~3.6~6.8 | 0.14 | 0.7 | 7000 | 0.045 | 1.60 | 5.20 | 0.205 | 31.6 | |
| BA3510MV05X | 5 | 1.8~3.6~6.8 | 0.16 | 0.8 | 7500 | 0.047 | 1.67 | 5.87 | 0.231 | 33.5 | |
| BA3510VM05X | 5 | 1.8~3.6~6.8 | 0.18 | 0.9 | 8000 | 0.053 | 1.86 | 6.92 | 0.272 | 34.9 | |
| BA3510H05X | 5 | 1.8~3.6~6.8 | 0.2 | 1.0 | 8500 | 0.056 | 1.98 | 8.05 | 0.317 | 36.1 | |
| BA3510HH05X | 5 | 1.8~3.6~6.8 | 0.22 | 1.1 | 9000 | 0.061 | 2.14 | 9.10 | 0.358 | 37.4 | |
| BA3510HV05X | 5 | 1.8~3.6~6.8 | 0.25 | 1.25 | 9500 | 0.064 | 2.27 | 10.18 | 0.401 | 39.1 | |
| BA3510VH05X | 5 | 1.8~3.6~6.8 | 0.28 | 1.4 | 10000 | 0.067 | 2.38 | 11.58 | 0.456 | 40.0 | |
| BA3510LL12X | 12 | 7~13.5 | 0.042 | 0.5 | 5500 | 0.035 | 1.25 | 2.67 | 0.105 | 25.4 | |
| BA3510L12X | 12 | 7~13.5 | 0.05 | 0.6 | 6000 | 0.040 | 1.42 | 3.62 | 0.143 | 27.5 | |
Note: This video demonstrates the operation and performance of the BA3510VH05B 5v Low operating voltage Blower.
Need a Custom Modification?
We can customize voltage (5V/12V), wire length, and connectors. Prototypes ready in 48 hours.
