High pressure blower BA18089H02B-A
High pressure blower BA18089H02B-A

High pressure blower BA18089H02B-A

220V
14000rpm/min
Max 240.5cfm11.2kpa

Request a Sample
Download Datasheet

Technical Specifications

ModelBA18089H02B-A
Size209*191*145 mm
Operating Voltage220 VDC
Rated Current7.4 Amp
Rated Speed14000 RPM
Maximum Flow Rate240.5 CFM
Maximum Static Pressure11.2 kpa









structure drawing of BA1804L3.3X

PQ curve for BA1804L3.3X

Need a Custom Modification?

We can customize voltage (5V/12V), wire length, and connectors. Prototypes ready in 48 hours.

Contact Our Engineers
