BFB0405MA air blower

Voltage: DC 5V
Speed: 6500rpm
Current: 0.11A

Request a Sample

Ultra-Compact Size, Space Saving

The BFB0405MA blower features an ultra-compact design, small size, and light weight, allowing for easy integration into space-constrained equipment such as miniature instruments and portable ventilation products.

Stable Airflow, Precise Ventilation

The BFB0405MA blower is equipped with a high-precision centrifugal impeller, providing stable and uniform airflow for precise ventilation and heat dissipation, effectively protecting the normal operation of core components in supporting equipment.

Ultra-Quiet Operation, Low Interference

The BFB0405MA blower adopts an integrated noise-reducing structure and high-quality silent bearings, resulting in extremely low operating noise. It is suitable for indoor precision instruments, medical equipment, and locations with high environmental requirements.

High Reliability, Long Lifespan

The BFB0405MA blower uses high-quality corrosion-resistant materials and precision electronic components, exhibiting excellent stability, wear resistance, and long lifespan, enabling it to adapt to long-term continuous operation in various small equipment scenarios.

Technical Specifications

ModelBFB0405MA
Size40*40*10 mm
Operating Voltage5 VDC
Rated Current0.11 Amp
Rated Speed6500 RPM
Maximum Flow Rate2.3 CFM
Maximum Static Pressure78pa


Video Showcase

Need a Custom Modification?

We can customize voltage (5V/12V), wire length, and connectors. Prototypes ready in 48 hours.
